Insulated Carports and Pergolas Parts & Accessories

  • Insulated Carports Parts and accessories

    Our cantilever carport and pergola parts are engineered for strength and longevity.

    We use premium-grade parts and heavy-duty hardware to deliver superior strength for Australian conditions. Featuring long steel bases, extended L-connectors, wider strips, thicker aluminium profiles, and optional bracing kits for long-term durability.
Explore Sizes & Current Prices

Add More Strength to Cantilever Carports & Pergolas

  • Long Steel Base for carport installation in ground or on concrete - 2 in 1

    Long Steel Base - 150cm - 17kg Each

    Enhance the durability of your cantilever carports and pergolas with our long steel base. Weighing 17kg each, suitable for both on concrete and inground installation.

    • Up to 250cm post: Dig a 70 × 70 × 80 cm hole.
    • Up to 300cm post: Dig a 80 × 80 × 90 cm hole.

  • Cantilever Bracing Kit - Free with Every Cantilever

    Increase the longevity of your outdoor structures with our Cantilever Bracing Kits, ensuring extra protection during extreme weather.
Explore Sizes & Current Prices

Insulated Carports & Pergolas

This page will provide you comprehensive information about our

Cantilever Insulated Carports, Pergolas & custom size carports sometime referred as Carport Awnings.

A PDF instruction guide & a video link will be provided for a smooth installation experience.



Standard Sizes with Insulated Roof Panels:

  • Size: Width 3.0m x Length 4.0m with 2 Posts and Long Steel Bases = 215 Kg
  • Size: Width 3.0m x Length 5.0m with 3 Posts and Long Steel Bases = 280 Kg
  • Size: Width 3.0m x Length 6.0m with 3 Posts and Long Steel Bases= 305 Kg
  • Standard Post: 3.0m High


Posts Installation

Cantilever or L Shape Carports and Pergola as name suggested have posts on only one side of the structure.

These can be installed in two ways:

On Concrete Installation:

Secure the steel base to the concrete slab using the supplied dynabolts. Trim the post to your required height (maximum 250 cm). Ensure the concrete slab is at least 150 mm thick.

or

Buried in the ground installation:

Prepare a hole of the appropriate size. Set the long steel base into the hole and fill it with concrete. Allow a minimum of 24 hours for the concrete to fully cure before installing the post and frame.

  • Up to 250cm post: Dig a 70 × 70 × 80 cm hole.
  • Up to 300cm post: Dig a 80 × 80 × 90 cm hole.


Post Placement

The position of posts in L Shape, M Shape Carports and Pergolas is a little flexible. You can move them a little if needed, keeping the gap between the posts recommended as below:


LSIR - L Shape with Insulated Roof Panels

L Shape 3.0m x 4.0m - 2 Posts: The gap should be between 3.0m and 3.5m.

L Shape 3.0m x 5.0m - 3 Posts: The gap should be between 2.0m and 2.2m.

L Shape 3.0m x 6.0m - 3 Posts: The gap should be between 2.4m and 2.7m




FAQs for Carports

Can the post height be reduced/adjusted?
Yes, standard posts height is 3.0m and customer can cut them short from the bottom end.

Can we install the carport on a slopy driveway?
Yes definitely. By cutting one post shorter than the other, the level of the slope can be managed to have desired roof level.

Are the gutter and drain pipe included in the kit?
Yes, gutter, drain pipe, connector and elbows are included in the kit.

Can installed post height be higher than 2.5m?
Yes, the Long Steel Bases can be buried in the ground, then 3.0m post can be slid over and secured with bolts & screws.

Insulated Carport Installation Video
